Beyond Regex: Advanced PowerShell Code Analysis with ASTs

In this post I’ll be walking through an example of a (silly) request you might see at work and show you how you can leverage AST’s to update your codebase.

I highly recommend the official Creating Custom Rules Microsoft doc as they do an excellent good job describing what’s required for a PSScriptAnalyzer rule. My goal with this post is to help explain how I would approach and inspect the various components.

One day at work you’re given a task to remove and update code across your repositories. That could look like a few different things.

Some examples:

• Replacing old functions with new ones
• Identify the reuse of properties that should be unique (ID’s)
• Looking for code that doesn’t follow your orgs style

In this post we’ll start with a specific example, but keep in mind that this could apply to all sorts of things. Before we hop into the problem I’ll briefly cover how to inspect an AST and a few tricks on creating scriptblocks.

Abstract Syntax Tree - AST

#

An Abstract Syntax Tree (AST) is a hierarchical representation of the structure of source code. It breaks the code down into its syntactic components like functions, loops, and expressions. This allows us analyze and manipulate the code more intelligently because it can understand the context and relationships that plain text searches or regex can’t capture.

Creating & Inspecting the AST

#

There are several ways to look at the AST. I’ll show you 3 ways to create a scriptblock that you can inspect.

Inline Scriptblock

#

The easiest way is to create a scriptblock which is code wrapped in { and }. Here is an example of creating a scriptblock and reading it’s AST:

$scriptBlock = {
  New-Pizza
}

Create Scriptblock via Create Method

#

Sometimes you want to create a scriptblock by joining different files or creating one from a string.

$scriptBlock = [scriptblock]::Create('New-Pizza')

Create Scriptblock via Parser

#

Another way to do this is create a script block from a file.

$Tokens = $null
$Errors = $null
$scriptBlock = [System.Management.Automation.Language.Parser]::ParseFile(
  '.\PizzaGenerator.ps1',
  [ref]$Tokens,
  [ref]$Errors
)

.AST Property

#

Each of those $scriptblock variables would now have a property called AST. This is excellect way of inspecting how your code was parsed.

AST Types

#

You can run the following to get a list of all the possible AST’s to target. This grabs the AST type and looks for all the other types in the assembly. This filters to anything that’s a subclass of the AST type.

[System.Management.Automation.Language.Ast].Assembly.GetTypes() | Where-Object {
  $_.IsSubclassOf([System.Management.Automation.Language.Ast])
}

Problem

#

You have to identify where people are using two parameters together that shouldn’t go together. You could fix the code to warn or throw, but maybe this work is in preparation for a future change.

Our example:

So we want to look for code that might look like this:

# Maybe the call is on the same line
New-Pizza -Size 'Large' -Ingredients @('Ham','Pineapple')

# Or maybe the value comes from a variable
$ingredients = @('Ham','Pineapple')
New-Pizza -Size 'Medium' -Ingredients $ingredients

# Or maybe from a splat
$splat = @{
  Size = 'Small'
  Ingredients = $ingredients
}
New-Pizza @splat

Normally you might do a simple search to fix something like the first one. Find all lines with New-Pizza and contains Pineapple. A simple replace would probably not suffice but a regex could (e.g. something like s/(New-Pizza.*)'Pineapple'(.*)/$1$2/g). The problem is that could never work for the other two where the value is set on other lines or in variables. This is where AST’s can help us.

Step One: Find The Relevant Commands

#

The ast type has a method called FindAll that allows to quick return a list of all the AST’s that match our search. We want to find all the command calls for New-Pizza. We can then later check the parameters of each.

The [FindAll method] takes a predicate (a function that returns a true or false) and a boolean that says whether it will search recursively.

Our predicate will take in the $Ast properties and check if they’re the type of AST we care about (CommandAst). Then it will use a method found on CommandAst’s called GetCommandName() that returns a string of what the command name is (which would be New-Pizza in our example). Our predicate might look like this:

{
  param($Ast)
  $Ast -is [System.Management.Automation.Language.CommandAst] -and
  $Ast.GetCommandName() -eq 'New-Pizza'
}

All together:

$pizzas = $scriptBlock.Ast.FindAll(
  {
    param($Ast)
    $Ast -is [System.Management.Automation.Language.CommandAst] -and
    $Ast.GetCommandName() -eq 'New-Pizza'
  },
  $false
)

Step Two: Get the parameters

#

Looking at the results in $pizzas you’ll find that different call sites for the New Pizza command. I suggest looking at the different properties. Later we will make use of the extent property (which contains the value as a string, the line numbers, and much more.) For now we’ll look at the CommandElements.

CommandElements will contain a list of all the AST’s the make up the command line. The first will be a StringConstantExpressionAst. How do I know that? Because that’s what New-Pizza is! It’s a BareWord meaning it’s a string that isn’t surrounded by quotes. This means that the rest of the items compose the list of parameters.

CommandParameterAst is the type of all the parameters. In a simple example we could simply say each item after a CommandParameterAst is it’s value. So -A Apple -B Bear would be A is the CommandParameterAst and the value right after would be the value being passed. For now we’ll solve that and revisit the more complex cases (e.g. variables, switches, and splats).

So we should create a simple loop and walk down the values noting where we find CommandParameterAst and grabbing the values for the item right after.

For this example let’s just grab the first one and set it as $CommandAst. Then we will inspect it to get the values.

$CommandAst = $pizzas[0]
$commandElements = $CommandAst.CommandElements
# Create a hash to hold the parameter name as the key, and the value
$parameterHash = @{}
for($i=1; $i -lt $commandElements.Count; $i++){
  # Switch on type
  switch ($commandElements[$i].GetType().Name){
    'CommandParameterAst' {
      $parameterName = $commandElements[$i].ParameterName
    }
    default {
      # Grab the string from the extent
      $value = $commandElements[$i].SafeGetValue()
      $parameterHash[$parameterName] = $value
    }
  }
}

So now we have the command and it’s parameters.The next thing would be to find where the value of the Ingredients property contains Pineapple.

# You might want to skip any call sites where maybe the ingredients parameter isn't set.
if(-not $parametersHash.ContainsKey('Ingredients')){ continue }
# Now we want to check if the Ingredients parameter contains Pineapple
if($parametersHash['Ingredients'].Contains('Pineapple')){
  # If we're in this block then we know this call needs fixing!
}

Step Four: The Extent

#

So we’re looping through the code and we’ve found a block that might need to be fixed. How do we where that is? What does that line in the code look like? This is where the extent can help us.

# Let's look at the CommandAST
$CommandAst.Extent

The extent property contains information on the script position, start/end line and column numbers. It also contains the Text representation of the command.

The extent is what PSScriptAnalyzer uses to figure out what to highlight. It’s also how VSCode can highlight what text needs to be fixed.

Step Five: Write a Rule

#

Taking what we learned up to this point we have enough to write a basic rule to identify any New-Pizza calls with a Pineapple ingredient.

<#
.SYNOPSIS
Checks for Pineapple used with New-Pizza
.DESCRIPTION
Contaso has decided that pineapple is no longer allowed.
.EXAMPLE
Measure-PineappleOnPizza -ScriptBlockAst $ScriptBlockAst
.INPUTS
[System.Management.Automation.Language.ScriptBlockAst]
.OUTPUTS
[Microsoft.Windows.PowerShell.ScriptAnalyzer.Generic.DiagnosticRecord[]]
.NOTES
None
#>
function Measure-PineappleOnPizza
{
  [CmdletBinding()]
  [OutputType([Microsoft.Windows.PowerShell.ScriptAnalyzer.Generic.DiagnosticRecord[]])]
  Param
  (
    [Parameter(Mandatory = $true)]
    [ValidateNotNullOrEmpty()]
    [System.Management.Automation.Language.ScriptBlockAst]
    $ScriptBlockAst
  )

Process
  {
    $results = @()
    try
    {
      # Finds all New-Pizza
      [ScriptBlock]$predicate = {
          param($Ast)
          $Ast -is [System.Management.Automation.Language.CommandAst] -and
          $Ast.GetCommandName() -eq 'New-Pizza'
      }
      [System.Management.Automation.Language.Ast[]]$pizzas  = $ScriptBlockAst.FindAll($predicate, $true)
      foreach($CommandAst in $pizzas){
        $commandElements = $CommandAst.CommandElements
        #region Gather Parameters
        # Create a hash to hold the parameter name as the key, and the value
        $parameterHash = @{}
        for($i=1; $i -lt $commandElements.Count; $i++){
          # Switch on type
          switch ($commandElements[$i].GetType().Name){
            'CommandParameterAst' {
              $parameterName = $commandElements[$i].ParameterName
            }
            default {
              # Grab the string from the extent
              $value = $commandElements[$i].SafeGetValue()
              $parameterHash[$parameterName] = $value
            }
          }
        }
        #endregion

        # Skip any call sites where maybe the ingredients parameter isn't set.
        if(-not $parametersHash.ContainsKey('Ingredients')){ continue }
        # Now we want to check if the Ingredients parameter contains Pineapple
        if($parametersHash['Ingredients'].Contains('Pineapple')){
          # If we're in this block then we know this call needs fixing!
          $result = [Microsoft.Windows.PowerShell.ScriptAnalyzer.Generic.DiagnosticRecord]@{
              'Message' = "Didn't you get the memo? No more pineapple on pizza!"
              'Extent' = $CommandAst.Extent
              'RuleName' = $PSCmdlet.MyInvocation.InvocationName
              'Severity' = 'Information'
          }
          $results += $result
        }
      }
      return $results
    }
    catch
    {
        $PSCmdlet.ThrowTerminatingError($PSItem)
    }
  }
}

Read More

#

This is an extremely complex topic. Don’t get discouraged if it doesn’t click immediately or you’re having trouble understanding. I recommend reading a few other great posts.

• Runspaces Simplified (as much as possible)
• Searching the PowerShell Abstract Syntax Tree
• Using the AST to Find Module Dependencies in PowerShell Functions and Scripts
• Learn about the PowerShell Abstract Syntax Tree (AST) - Part 2
